Key takeaways
- A chronograph is a watch that can measure elapsed time. It is a function, not a style.
- A chronometer is something else entirely: a standard of accuracy, not a stopwatch.
- The first chronograph dates to 1680 and did not time anything. It chimed.
- Early examples were called squeeze watches because you pressed a pin sticking out of the case.
- Subdials are the usual giveaway, but they are not what makes a watch a chronograph.
Chronograph is the most misused word in watches, closely followed by chronometer, and the two get swapped constantly. They are not variations on a theme. They describe completely different properties, and a watch can be one, both or neither.
Here is what each word actually means, where the chronograph came from, and what those extra dials are doing.
What is a chronograph?
A watch that can measure elapsed time. Britannica defines it as an instrument that can measure elapsed time in split seconds, seconds or minutes, and notes that it differs from a conventional timepiece by performing functions beyond simply telling mean time.
That is the whole definition, and it is a definition of behavior. Start it, stop it, read how long something took. The humble stopwatch is a form of chronograph.
Some chronographs go further and indicate day, month, year and phases of the moon on separate dials set into the face. Those are additions, not requirements.
Is a chronograph the same as a chronometer?
No, and this is the distinction worth learning. A chronometer, per Britannica, is a portable timekeeping device of great accuracy, historically one used to determine longitude at sea.
| Chronograph | Chronometer | |
|---|---|---|
| Describes | A function | A standard of accuracy |
| Answers | How long did that take? | What time is it, precisely? |
| Origin of the word | Timepieces with added functions | Coined 1779 by John Arnold |
| Can a watch be both? | Yes. They measure different things. | |
One is about measuring an interval. The other is about not drifting. A watch can have a stopwatch function and keep poor time, or keep superb time with no stopwatch at all.
Who invented the chronograph?
Daniel Quare, an English clockmaker, in 1680. The surprise is what it did: Britannica describes it as a form of repeating watch that sounded the hours when a lever was pushed.
So the first chronograph did not time anything. It chimed. The through-line to the modern instrument is the idea of a watch that does something extra when you press it, rather than the specific job of measuring an interval.
That is a useful corrective to how these things are usually sold. The chronograph did not begin as a racing instrument. It began as a watch with a button.
Why were they called squeeze watches?
Because you squeezed them. The earliest examples required the wearer to push or squeeze a pin protruding from the case to trigger the mechanism, which is how the name arose.
The pusher on a modern chronograph is the direct descendant of that pin. It moved to the side of the case, acquired a second one, and became the defining visual feature of the type, but the gesture is identical.
What do the subdials actually do?
They hold the elapsed time so the main hands can carry on telling you the actual time. That is the entire design problem a chronograph solves, and everything about the layout follows from it.
A typical arrangement uses a central sweep hand for elapsed seconds, with small registers counting elapsed minutes and hours. Keeping those on separate dials is what lets one watch answer two questions at once without the readings colliding.
The moon phase, date and month indications Britannica mentions sit on the same principle: extra information, given its own window, superimposed on the face.
How do pilots use one?
For elapsed flight time and, less obviously, for ground speed. Britannica describes the aircraft instrument: the pilot pushes a button at takeoff, pushes it again on landing, and reads the elapsed time in hours, minutes and split seconds.
The navigation use is the more interesting one. Time two known points, either visually or by radio signal, and you can calculate ground speed. Given any two of speed, time and distance, the chronograph gives you the third.
This is why the instrument became associated with cockpits and racing rather than offices. It is a calculator you wear.
Does a watch need subdials to be a chronograph?
No. Subdials are the usual consequence of the function, not the function itself. A single-register chronograph is still a chronograph, and a watch with three purely decorative subdials is not one.
This is where most confusion in shop windows comes from. Subdials read as technical, so they get used as styling even where nothing is being measured. The test is whether it starts, stops and resets.
If the pushers do nothing, it is a watch that looks like a chronograph.
What was the longitude problem?
The reason the chronometer exists, and one of the great engineering stories. Ordinary clocks were useless at sea because temperature changes and the ship's motion destroyed their accuracy, and without accurate time you cannot fix longitude.
In 1714 the British government offered twenty thousand pounds for a means of determining longitude within thirty geographical miles at the end of a six-week voyage. Britannica notes what that demanded: a timekeeper accurate to within three seconds per day, better than the best pendulum clocks on land at the time.
John Harrison, a self-taught carpenter, built four marine timekeepers, and the fourth effectively won the prize. The word chronometer itself came later, used in 1779 by clockmaker John Arnold for his pocket chronometer numbered 1/36.
Why does a chronograph dial look the way it does?
Because every element is solving a legibility problem under time pressure. Contrasting subdials exist so you can read a small register at a glance. The outer scale exists so the sweep hand lands against something countable.
That is why chronograph dials work so well as graphic objects. Nothing on the face is decorative in origin, and the result is a composition of circles inside a circle with a strict internal logic, which is more or less the definition of good design.
It is also why a chronograph reads as serious on a wall in a way a plain dial does not. The complexity is legible as purpose.
Why did motor racing adopt the chronograph?
Because early motor racing was a timing contest before it was anything else. Britannica dates the first organized automobile competition to 1894, a reliability run from Paris to Rouen won at an average speed of 16.4 kph, and the first true race to 1895, Paris to Bordeaux and back, won at 24.15 kph. Those results are averages, which means somebody had to record a start and a finish and do arithmetic on the difference.
Endurance racing then made the instrument permanent. The 24 Hours of Le Mans has run since 1923, and since 1928 the winner has been the car covering the greatest distance in a 24-hour period. A race decided that way is a day-long exercise in elapsed time: lap after lap logged, fuel windows counted, driver stints measured. The chronograph was the pit wall's instrument long before it was a design cue on a dial.
This is why the racing chronograph looks the way it does. Large contrasting registers, a tachymeter track around the edge for converting elapsed seconds into speed, and pushers big enough to find without looking down are all answers to the problem of reading a number while something else demands your attention.
What should you check before buying a chronograph?
Most of the disappointment with chronographs comes from buying the look and then discovering the function is awkward. Four checks catch nearly all of it.
- Press the pushers. A chronograph you dislike operating is a chronograph you will never start, and the feel varies enormously between mechanisms.
- Read the running seconds. On many dials the small seconds hand that proves the watch is alive is the least legible thing on it.
- Check the reset. The hands should snap back to zero cleanly, with no hesitation and no hand sitting slightly off the mark.
- Decide whether you want the scale. A tachymeter is genuinely useful if you time things over a known distance, and pure decoration if you do not.
Which watch imagery works on a wall?
Close, and large. A watch photographed at arm's length reads as a catalog shot; a dial filling most of the canvas reads as architecture, and all the detail that justifies the object becomes visible.
- Go big or do not bother. A small watch print reads as a magazine page torn out.
- Dial color decides the room, not the case metal. A green or blue dial anchors a palette; a white one disappears into a pale wall.
- One watch per wall. Two compete and the detail in both is lost.
- Hang it where people stand close enough to read the subdials, which usually means a study, office or hallway rather than across a living room.
The range is in the watch wall art collection. If the appeal is the idea of time rather than the object, Seneca on time covers the other half of it.
Featured watch pieces
Frequently asked questions
What is a chronograph watch?
A watch that can measure elapsed time in split seconds, seconds or minutes, alongside telling the time. It is defined by that function, not by having subdials.
What is the difference between a chronograph and a chronometer?
A chronograph measures elapsed time. A chronometer is a portable timekeeper of great accuracy, historically used to find longitude at sea. One is a function, the other a standard, and a watch can be both.
Who invented the chronograph?
English clockmaker Daniel Quare, in 1680. His version was a repeating watch that sounded the hours when a lever was pushed, so the first chronograph chimed rather than timed.
Why were early chronographs called squeeze watches?
Because the wearer had to push or squeeze a pin protruding from the case to operate them. The modern pusher on the side of the case is the direct descendant of that pin.
Do all chronographs have subdials?
No. Subdials are the common way of displaying elapsed minutes and hours, but they are a consequence of the function. A watch with purely decorative subdials is not a chronograph.
